Lft-g®Ntev fiber ntau txhawb polypropylene rau nkoj duav path
Lub zog los ntawm cov dej: cov khoom siv zoo tshaj rau cov kev ua tau zoo ntawm cov khoom siv
Rau cov neeg nyiam thiab cov tub txawg tib yam, kev ua tau zoo ntawm lub nkoj duav khawm rau nws cov khoom muaj pes tsawg leeg.Lft-g®Pp lgf30Tawm los ua cov tshuaj zoo tshaj plaws rau kev ua haujlwm crychat duav, muab ib qho kev tsim lub teeb ci, kev tsim lub zog, thiab cov tsis txaus ntseeg hauv cov tsiaj muaj dej. Los ntawm kev sib txuas ua ke ntev iav fibers rau hauv lub zog polypropylene matrix, lft-g®PP LGF30 ua tiav lub zog zoo dua-rau-qhov hnyav piv, txhais lus ncaj qha rau kev hloov paddling thiab ua kom zoo dua hloov hluav taws xob nrog txhua qhov mob stroke. Cov qib tshwj xeeb ntawm LFT PP LGF30 yog meticulously tsim kev tsim kho, muab cov qauv kev ncaj ncees, thiab ntev ntev reserle yuav tsum tau conquers ib qho dej.
Qhov tseem ceeb ntawm LFT-G®PP LGF30 rau cov nkoj duav
- Lub teeb yuag thiab nkees-txo:Qhov qis dua ntawm PP LGF30 ua kom lub teeb yuag, txo qis kev nkees thaum lub sijhawm ntev ntev.
- Tshwj xeeb muaj zog thiab nruj:Lub tawb iav ntev fiber ntau ntxiv rau lub zog zoo tshaj lub zog thiab nruj me ntsis, cia rau kev hloov hluav taws xob zoo thiab muaj zog strokes los ntawm cov dej.
- Zoo heev deem thiab cuam tshuam kuj:PP LGF30 tuaj yeem tiv thaiv kev ntxhov siab tsis tu ncua, suav nrog kev cuam tshuam nrog cov pob zeb, khib nyiab, thiab qee zaus kev sib tsoo kom poob, ua kom muaj lub duav ntev-ntev.
- Superior dej tsis kam thiab buotancy:Lub taub dej tsis kam ntawm polypropylene, txhim kho los ntawm kev siv fiber ntau lub zog, ua kom cov duav tau cuam tshuam nrog cov dej ntev ntev thiab tswj kev ua kom lub sijhawm ntev.
- Kuj rau UV Kev Ruaj Ntseg:Cov khoom siv tau tsim los tiv thaiv lub caij nyoog raug tshav ntuj, tiv thaiv kev ua kom tsis txhob txwm thiab tswj lub duav kev ua tau zoo thiab kev tshwm sim sijhawm dhau lub sijhawm.
- Tsim Versatility thiab Ergonomics:Cov pwm ua tau zoo tshaj plaws ntawm PP LGF30 tso cai rau kev tsim ntawm Ergonomically Tsim Digital thiab cov leeg rau cov paddling zoo thiab txuag tau zoo.
- Tshuaj lom neeg Kuj:PP LGF30 yog tiv taus ntau yam tshuaj muaj nyob hauv cov dej thiab cov tub rog ib puag ncig, txuas ntxiv txhim kho nws txoj kev ntev.
Los ntawm kev xaivLft-g®Pp lgf30Rau koj lub nkoj duav feem, koj tau nqis peev rau hauv cov khoom uas xa cov khoom tsis muaj kev ua tau zoo, ua kom tsis tu ncua, thiab kev nplij siab ntawm cov dej. Peb qhov tshwj xeeb Lft PP qib txhawb nqa cov tuam ntxhab los tsim cov khoom zoo, thiab muaj zog paddles uas tau raws li kev xav tau ntawm cov kev ua si thiab cov ntaub ntawv tshaj lij. Tshawb nrhiav txoj kev muaj peev xwm thiab tus khub nrog peb los ua rau engineer rau cov neeg ua haujlwm siab tom ntej no.
Hu rau peb cov ntaub ntawv cov ntaub ntawv rau duav kev thov
PP LGF30 Cov Ntawv Cov Ntaub Ntawv
Cov ntaub ntawv no muab cov ntaub ntawv ua haujlwm rau 30% ntev fiber ntau txhawb polypropylene (lft-g® PP LGF30) cov khoom siv. Cov ntaub ntawv nthuav tawm ntawm no yog raws li cov txiaj ntsig tau txais los ntawmXiamen lft-g®Cov Khoom Siv Khoom Siv. Thov saib cov ntaub ntawv tshwj xeeb ntawm koj qhov kev pab cuam rau cov khoom siv LFT cov nqi.
Cov Khoom Siv Neeg Kho Tshuab
| Ntiag tug | Tus nqi | Ib yam | Kuaj Tus Qauv |
|---|---|---|---|
| Lub zog tensile | 122±5 | MPa | Iso 527-1 |
| Tensile modulus | 6900-7380 | MPa | Iso 527-1 |
| Elongation thaum so | 1.5-2.5 | % | Iso 527-1 |
| Lub zog flexural | 150-160 | MPa | Iso 178 |
| FLEXURAL Modulus | 5000-6000 | MPa | Iso 178 |
| Nonched izod cuam tshuam lub zog (+23 degree) | 34-42 | KJ / M² | ISO 180 / 1A |
| Nonched izod cuam tshuam lub zog (-30 degree) | 30-35 | KJ / M² | ISO 180 / 1A |
Thermal Khoom
| Ntiag tug | Tus nqi | Ib yam | Kuaj Tus Qauv |
|---|---|---|---|
| Melting kub | 150-165 | tiv kis | ISO 11357 |
|
Thaum tshav kub kub deflection kub (HDT / A, 1.8 MPA) |
158±2 | tiv kis | Iso 75-1 |
| Coefficient ntawm linear thermal expansion | 10-20 | x 10-6/K | ISO 11359 |
Lwm cov khoom
| Ntiag tug | Tus nqi | Ib yam | Kuaj Tus Qauv |
|---|---|---|---|
| Ceev | 1.11±0.01 | g / cm³ | ISO 1183 |
| Flammability (UL 94) | HB | - | UL 94 |
| Kev nqus dej noo (24 teev) | 0.01-0.03 | % | ISO 62 |
Cov Lus Qhia thiab Cov Ntaub Ntawv Ntxiv:
Cov ntaub ntawv tau los:Cov ntaub ntawv no tau muab tso ua ke raws li cov cai pom muaj nyob hauv kev tshaj tawm muaj pov thawj los ntawmXiamen lft-g® PP LGF30 KHOOM RAUG tuam ntxhab. Rau cov ntaub ntawv qhia meej thiab cov ntaub ntawv tshwj xeeb rau koj cov programme, thov sab laj Datasheet muab los ntawmPeb cov khoom siv.
Download tau tiav LFT PP cov ntaub ntawv ntawv PDF
