Name: Tuam Tshoj PP GF40 (LGF40%) Ntev iav Fiber Chaw tsim tshuaj paus|LFT-G®
Brand: LFT-G
SKU: 304093520

LFT-G® Homo PP 40% Ntev iav Fiber Structural Polymer

Standard luviav fiber ppcov tebchaw ib txwm ua tsis tau raws li kev ntxhov siab txuas ntxiv vim yog fiber ntau rub - tawm. Peb cov tshuab pultrusion siab heev khaws 10-12mm fiber ntau ntev hauv cov pellet. Thaum txhaj tshuaj molding, cov fibers txuas txuas txuas ntxiv los tsim ib qho 3D cov qauv mesh sab hauv, ua rau nws yog qhov tseem ceeb.hlau hloovtov rau complex automotive thiab industrial sib dhos.

LFT-G® Homo PP GF40 LGF40 High Rigidity Polymer

Core Advantages:

● Extreme Structural Rigidity:8,500 MPa flexural modulus effortlessly hloov cam khwb cia txhuas brackets.
● Zoo Dynamic Fatigue:Nruam 3D fiber ntau network tiv thaiv kev tawg tawm hauv qab kev co.
● Aerospace-Txuag Qib Nyhav:Tsawg ntom ntom ntawm 1.22 g / cm³ ua rau txo qhov hnyav ntawm cov hlau.
● Zero Hydrolysis Kev txhawj xeeb:Tsis zoo li Nylon, qhov sib xyaw hydrophobic no tuav lub zog tag nrho hauv cov av noo siab.

Lub Fatigue & Creep Frontier (Dynamic Load Survival)

Tsis yog tag nrho 40% iav ntim cov yas ua kom sib npaug hauv kev thauj khoom. Saib yog vim li cas ntev fiber skeleton tiv thaiv kev ua haujlwm tsis ua haujlwm.

Txuj luv PP GF40
(Tus Competitor)

❌ Sustained Mechanical Loads:
- Polymer chains plam yooj yim.
- Ib feem dhau mus sai sai deformation.
- Dimensional Deviation: HIGH

⚠️

LFT-G® Homo PP LGF40
(Model: LFT-PP-GF40-NG04)

✅ Sustained Mechanical Loads:
- 10 hlifiberglassnetwork mechanically xauv matrix.
- Zero -zero creep expansion nyob rau hauv kev ntxhov siab.
- Dimensional raug:<0.1%

🛡️

Cov khoom siv zoo (NG04)

Cov txiaj ntsig hauv qab no yog cov ntaub ntawv raug rau LFT-G^®PP-LGF40 (Homopolymer Qib) thiab yog rau siv xwb. Cov ntaub ntawv yog rau qhuav-As-Moulded (DAM) xeev.Thov hu rau peb rau Daim Ntawv Teev Npe Cov Ntaub Ntawv (TDS).

Mechanical Properties

Khoom	Txoj Kev Xeem	Tus nqi (DAM)
Tensile Modulus	TS EN ISO 527	9,500 MPa
Tensile zog	TS EN ISO 527	135 MPa
Flexural Modulus	ISO 178	8,500 MPa
Flexural zog	ISO 178	190 MPa rau
Notched Izod cuam tshuam (23 degree)	ISO 180 / A	35-38 kJ/m²

Thermal & Physical Properties

Khoom	Txoj Kev Xeem	Tus nqi
Qhov ntom	TS EN ISO 1183	1.21 g / cm³
HDT (0.45 MPa)	ISO 75	150 degree
HDT (1.80 MPa)	ISO 75	159 degree
Pwm Shrinkage	TS EN ISO 294-4	0.1 - 0.2 %

Download Ua tiav LFT^®PP -LGF40 TDS (PDF)

Cov ntaub ntawv ua haujlwm

Cov txiaj ntsig hauv qab no yog cov lus pom zoo ua cov txheej txheem. Tiv thaiv qhov tseem ceebiav fiber ntau ntevnetwork los ntawm shearing thiab fiber ntau attrition, ib txwm siv ib tug tsawg - compression ntsia hlau, rov qab siab nyob rau hauv 50 psi, thiab loj rooj vag.

Parameter	Kev pom zoo
Qhuav kub	80 - 90 degree
Lub Sijhawm Qhuav	2 - 3 teev
Tsheb / Pub Thaj Chaw (Zone ①)	190 - 210 degree
Chaw / Melt Zone (Zone ②)	210 - 250 degree
Pem hauv ntej / Nozzle Temp (Zone ③)	220 - 240 degree
Pwm Kub	38 - 70 degree

Injection molding Process info for LFT-G Materials

Ntau-Cov Ntawv Thov Kev Lag Luam

Automotive Front End Module PP LGF40 NG04

Automotive Pem hauv ntej-End Modules

Lub tsheb pem hauv ntej- xaus thiab cov tsheb thauj khoom yuav tsum muaj kev ua haujlwm siab tshaj plaws los txhawb cov khoom tseem ceeb nyob rau hauv txoj kev loj tsis tu ncua. LFT-G^® wb gf40hloov tuag- nrum hlau sub- thav duab, xa mus txog 45% qhov hnyav txo thiab qhov tshwj xeeb cuam tshuam nqus yam tsis dhau qhov kev nyab xeeb ntawm kev sib tsoo.

Washing Machine Plastic Drum Bracket PP LGF

Tshuab ntxhua khaub ncaws

Zoo kawg nkaus optimizedrau lub tshuab ntxhua khaub ncaws yasmanufacturing, xws li cov tub sab sab thiab nruas lifters. Qhov ntom ntom 40% ntev fiber ntau pob txha tau lees paub qhov zoo ntawm qhov ruaj khov thiab qaug zog lub neej nyob rau hauv lub voj voog khaus, ua haujlwm zoo dua cov nylon luv luv fiber ntau hauv qhov chaw ntub dej.

Industrial Water Pump Housing PP GF40

Industrial Fluid Systems

Hnyav- cov khoom siv dej ua haujlwm yuav tsum muaj kev tiv thaiv corrosion nruj thiab xoom nkag hauv siab. Qhov no 40%iav fiber pphloov cov cam khwb cia hlau vaj tse, tiv thaiv cov kua xau thiab cov txheej txheem warpage thaum tam sim txo cov nqi khoom thiab tag nrho cov khoom hnyav.

Cov lus nug nquag nug (FAQ)

Q: Vim li cas thiaj xaiv Homopolymer hloov Copolymer rau PP GF40?

A: Homopolymer Polypropylene muab cov crystallinity ntau dua li Copolymer, ua rau lub zog tensile zoo dua, tsis muaj zog (~ 9.5 GPa modulus), thiab ua kom sov zoo dua. Backed los ntawm 3D nruam fiber skeleton, nws kov yeej cov keeb kwm brittleness ntawm homopolymers, xa ib qho zoo tagnrhoqauv yas ib feemsib xyaw.

Q: Ua li cas PP GF40 piv rau PA6 GF30 hauv kev hloov hlau?

A: Nylon 6 absorbs dej los ntawm huab cua puag ncig, ua rau 50% poob ntawm lub zog thiab qhov sib txawv. LFT-G® PP LGF40 absorbs xoom ya raws, ua kom ruaj khov nyob rau hauv qhov chaw ntub dej. Nws kuj tseem yog 15-20% sib dua thiab ua tau zoo dua.

Q: Dab tsi yog txoj cai tseem ceeb ntawm kev khaws cov fiber ntau ntev?

A: Cov ntsia hlau siab shear shatters 10mm fibers rau hauv cov qauv luv fibers. Txhawm rau zam qhov no, cov neeg ua haujlwm yuav tsum tso siab rov qab qis dua 50 psi, siv qis - compression ntsia hlau tsim, kho qhov kev txhaj tshuaj kom qeeb - mus rau - nruab nrab, thiab nthuav dav lub qhov rooj mus rau qhov tsawg kawg nkaus ntawm 3 hli.

Nrhiav rau Elite Hlau Hloov ntawm Lower Mass?

Tsis txhob cuam tshuam nrog warp, creep, thiab hnyav hlau Cheebtsam. Hu rau LFT-G^®engineering pab neeg rau cov khoom customization thiab DFM kev taw qhia.

Thov PP GF40 Quote
