Lft-g®Ntev fiber ntau txhawb polypropylene rau cov ntxuam txuas
Powering Airflow, ua kom kawg: cov khoom siv zoo tshaj rau cov ntxuam txuas
Hauv cov chaw muaj kev muaj, txhim kho dav hlau txhim khu kev qha thiab muaj txiaj ntsig zoo rau kev txias, qhov cua, thiab kev tswj cov txheej txheem. Cov kev ua tau zoo thiab lub neej ntawm cov kiv cua hnyav nyob ntawm cov ntaub ntawv siv rau lawv cov hniav.Lft-g®Pp lgf40Tawm los ua kev xaiv ua ntej premier rau kev ua kom muaj kev sib txuas ua ke ntawm lub teeb ci ntsa iab, muaj zog ruaj khov, thiab zoo dua qub. Los ntawm embedding cov chaw thau khoom tseem ceeb ntawm cov iav ntev ntev (40%) tsis pub muaj txiaj ntsig zoo polypropylene matrix, lft-g®PP LGF40 tau ua tiav qhov zoo tshaj plaws-rau-qhov hnyav piv, ua rau kev tsim cov teeb meem tseem ceeb heev uas muaj cov ntxuam ntxuam. Qhov tshwj xeeb qib kawm ntawm LFT PP LGF40 yog cov kws tshaj lij ntawm kev ua haujlwm nrawm, thiab muaj kev cuam tshuam los ntawm kev ua haujlwm ntawm huab cua ua rau muaj cov chaw muaj kev lag luam. Tsis tas li ntawd, PP LGF40 muaj kev tiv thaiv zoo heev rau noo noo thiab muaj ntau yam tshuaj lom neeg, ua kom muaj kev pabcuam siab tau zoo thiab lub neej ntev txawm nyob hauv cov kev sib tw ntawm huab cua. Nws qhov seem ruaj khov tswj cov hniav zoo saib cov hniav geometry rau kev sib xws thiab muaj cua ntau.
Qhov tseem ceeb ntawm LFT-G®PP LGF40 RAU COV KHOOM CUA KOOM
- Lub zog siab thiab nruj:Withstands qhov tseem ceeb centrifugal rog tsim tawm ntawm kev tig ceev ceev, kom muaj kev ncaj ncees hniav thiab kev ua haujlwm nyab xeeb.
- Foob Zoo Tshaj:Tus tsim kho rau kev ua haujlwm tas mus li, tiv thaiv cov khoom tsis cuam tshuam nyob rau hauv kev rov ua kom muaj kev ntxhov siab ntev dua.
- Kev Cuam Tshuam:Muab cov tawv muaj zog tiv thaiv kev puas tsuaj los ntawm cov kev cuam tshuam me me nrog cov khib nyiab me me hauv lub airflow.
- Lub Hnav Tsho:Txo kev sib hloov ua ke, ua rau lub sijhawm rov qab teb dua, kev noj haus qis dua, thiab txo cov hnav rau lub cev muaj zog thiab kabmob.
- Qhov seem ruaj khov:Saib xyuas cov hniav zoo geometry thoob plaws kev sib txawv thiab cov av noo, ua kom muaj kev ua haujlwm zoo ib yam thiab ua tau zoo.
- Corrosion thiab Tshuaj Txhuam Kuj:Ua yeeb yam ntseeg tau nyob rau hauv ib puag ncig uas raug rau dej noo, tshuaj lom neeg, lossis corrosive cov ntsiab yog kev txhawj xeeb.
- Tsim qauv tsim:Cov pwm zoo heev tso cai rau cov nyom thiab aerodynamically optimized hniav cov profiles kom ua kom dav dav Airflow efficiency.
Los ntawm kev xaiv ** litft-g®PP LGF40 ** RAU KOJ TUS KHEEJ FANE NPLAIM, Koj tab tom nqis peev hauv cov khoom uas xa cov khoom tsis muaj kev ua tiav, ua haujlwm tau zoo, thiab kav ntev rau hauv kev siv cov kev siv uas tau xav tau. Peb qhov tshwj xeeb LFT PP qib muaj zog txhawb cov kiv cua los ua cov kiv cua sib zog, ua rau muaj kev ua haujlwm zoo thiab txo tus nqi txij nkawm. Tshawb nrhiav txoj kev muaj peev xwm thiab tus khub nrog peb rau engineer rau cov tiam tom ntej ntawm kev ua haujlwm siab muaj kiv cua hniav tuaj yeem.
Rau cov ntaub ntawv ntau ntxiv, thov saib rau covkev qhia tshwj xeebhauv qab, lossis
Hu rau peb cov kws tshaj lij rau muaj ntxuam kiv cua cov ntsiab lus
Lft-g® PP LGF40 cov ntaub ntawv cov ntaub ntawv rau cov ntxuam tawg
Cov ntaub ntawv no muab cov ntaub ntawv ua haujlwm rau 40% ntev fiber ntau txhawb polypropylene (lft-g® PP LGF40) cov khoom siv, tshwj xeeb tshwj xeeb rau kev siv kiv cua hniav kev siv. Cov ntaub ntawv nthuav tawm ntawm no yog raws cov txiaj ntsig tau txais los ntawm cov khoom siv thoob ntiaj teb thiab cov qauv. Thov saib cov ntaub ntawv tshwj xeeb ntawm koj qhov kev pab cuam rau cov khoom siv LFT cov nqi.
Cov Khoom Siv Neeg Kho Tshuab
| Ntiag tug | Tus nqi | Ib yam | Kuaj Tus Qauv |
|---|---|---|---|
| Lub zog tensile | 120-130 | MPa | Iso 527-1 |
| Tensile modulus | 7000-9000 | MPa | Iso 527-1 |
| Elongation thaum so | 1.8-2.5 | % | Iso 527-1 |
| Lub zog flexural | 170-220 | MPa | Iso 178 |
| FLEXURAL Modulus | 6000-8000 | MPa | Iso 178 |
| Nonched izod cuam tshuam lub zog (+23 degree) | 36-58 | KJ \/ M² | ISO 180 \/ 1A |
| Nonched izod cuam tshuam lub zog (-30 degree) | 36-55 | KJ \/ M² | ISO 180 \/ 1A |
| Qaug zog dag zog (ntawm 106mus ncig) | 50-60 | MPa | Raws li kev sim sab hauv |
Thermal Khoom
| Ntiag tug | Tus nqi | Ib yam | Kuaj Tus Qauv |
|---|---|---|---|
| Melting kub | 210-250 | tiv kis | ISO 11357 |
|
Thaum tshav kub kub deflection kub (HDT \/ A, 1.8 MPA) |
159 | tiv kis | Iso 75-1 |
| Coefficient ntawm linear thermal expansion | 4-6 | x 10-5/K | ISO 11359 |
Lwm cov khoom
| Ntiag tug | Tus nqi | Ib yam | Kuaj Tus Qauv |
|---|---|---|---|
| Ceev | 1.10-1.26 | g \/ cm³ | ISO 1183 |
| Flammability (UL 94) | HB lossis V -2 (nyob ntawm qib) | - | UL 94 |
| Kev nqus dej noo (24 teev) | <0.05 | % | ISO 62 |
| Shrinkage tus nqi (pwm shrinkage) | 0.5-1.0 | % | ASTM D -955 |
| Ib puag ncig tsis kam (sab nraum zoov raug) | Zoo (nrog tsim nyog UV stabilizers) | - | ISO 4892 |
Kev Siv Tshuaj Tiv Thaiv (Raug)
Lft-g® PP LGF40 cov khoom ua pov thawj zoo tsis kam rau cov tshuaj hauv qab no cuam tshuam rau cov chaw muaj kev lag luam:
- Dej thiab av noo - zoo heev
- Diluted acids - zoo
- Diluted alkalies - zoo
- Ntau cov kuab tshuaj - ncaj ncees rau qhov zoo (sab laj cov kab kos lus nug)
- Roj thiab greases - ncaj ncees rau qhov zoo
Cov ntaub ntawv ua (raug)
Cov kev pom zoo ua cov haujlwm rau LFT-G® PP LGF40 rau kev txhaj tshuaj molding ntawm muaj ntxuam tawg:
- MlT kub: 200-240 degree
- Pwm kub: {30-60 degree
- Kev Txhaj Tshuaj Ceev: Nruab nrab rau siab (optimized rau fiber ntau khaws cia thiab kev faib tawm tsis sib xws)
- Tuav siab: optimized los txo warpage thiab kom ntseeg tau hniav ncaj thiab sib npaug
Cov Lus Qhia thiab Cov Ntaub Ntawv Ntxiv:
Cov ntaub ntawv tau los:Cov ntaub ntawv no tau muab tso ua ke raws li qhov tseem ceeb rau PP LGF40 los ntawm cov khoom siv thoob ntiaj teb cov khoom lag luam thiab cov qauv. Kev qaug zog yog raws kev sim sab hauv. Kev tiv thaiv ib puag ncig tuaj yeem txhim kho nrog cov stabilizers tshwj xeeb rau sab nraum zoov lossis sab nraud.Lft-g® PP LGF40 muaj kev sib npaug ntawm lub zog siab, txhav, qaug zog tsis kam, thiab cuam tshuam cov khoom siv nyuaj rau kev xav tau ntxuam. Nws lub teeb yuag sib zog ua rau lub zog txuag hluav taws xob, thiab nws txoj kev ib puag ncig thiab tshuaj lom neeg tiv thaiv kom ruaj khov hauv ntau qhov chaw muaj kev lag luam.Thov sab laj cov ntaub ntawv ua raws cai raws li kev siv kiv cua muaj kiv cua. Txog cov qauv thiab cov ntaub ntawv tshwj xeeb rau koj cov programme, thov sab laj cov ntaub ntawv muab los ntawm koj cov khoom xa khoom.
Download tau tiav LFT PP LGF40 cov ntaub ntawv PDF
