Lft-g®Ntev fiber ntau txhawb polypropylene rau automotive tshav ntuj brackef
Cov kev ua haujlwm du, kav ntev txhawb: cov ntaub ntawv zoo tshaj plaws rau kev kho tshav ntuj kho tshav ntuj
Automotive sunroof tshuab yog cov txheej txheem uas tuaj yeem muab cov qauv kev pab cuam ib puag ncig ua ke, thiab txhawb nqa lub luag haujlwm ntawm cov khoom siv iav {}}Lft-g®Pp lgf30Tawm los ua cov tshuaj zoo cov lus siv rau kev ua kom muaj lub tshuab ua kom huv si thiab rub tawm hauv lub ntsej muag zoo nkauj hauv lub ntsej muag zoo nkauj®PP LGF30 muab kev sib npaug zoo ntawm lub zog ntawm LGF30 yog cov qauv kev ntseeg siab nyob rau hauv qhov chaw muaj kev ntxhov siab nyob rau hauv cov kev hloov pauv loj hauv qab cov Lub tsev vov tsev, ua kom muaj kev ua haujlwm du thiab tsis xwm yeem ntawm tshav ntuj tshuab {}} lft-g®PP LGF30 kuj tseem ua rau lub luag rau kev sib xyaw ua ke rau kev sib koom ua ke hlau tsis zoo rau kev sib xyaw ua ke, yooj yim {}}
Qhov tseem ceeb ntawm LFT-G®PP LGF30 rau kev kho tshav ntuj kho tshav ntuj
- Optimized lub zog thiab nruj:Muab cov cuab yeej txhim khu kev qha rau lub vaj huam sib luag sunroof thiab tiv thaiv lub zog muaj feem xyuam hauv kev qhib thiab kaw .
- Tshwj tsis txaus siab qaug zog:Engineered kom thev dhau ntau lab ntawm kev ua haujlwm ntawm kev ua haujlwm, ua haujlwm ntev ua haujlwm tsis muaj cov khoom tsis taus.
- Superior tas ruaj khov:Tswj cov duab zoo thiab thev taus nyob rau hauv kev sib txawv kub muaj nyob ze ntawm lub tsheb ru tsev, ua kom muaj kev ua si du thiab zoo nkauj sunroof txav .
- Lub Hnav Tsho:Pab txhawb nqa lub tsheb hnyav tag kev tsis muaj cov qauv kev sib txuas lus ncaj qha .
- Suab nrov thiab kev co damping:Pab kom txo cov suab nrov thiab kev co kis tau los ntawm tshav ntuj tshav ntuj rau hauv lub tsev pheeb suab .
- Corrosion Kuj:Muab cov tshuaj tiv thaiv kev npau taws thiab ib puag ncig qhov sib xws piv rau cov khoom siv hlau .
- Tsim qauv tsim nyog thiab kev sib xyaw ua ke:Zoo heev pwm raug tso cai rau cov nyom, ntau-ua haujlwm bracket tsim, piv rau kev sib dhos yooj yim thiab txo qhov suav.
Los ntawm kev ncaj qha ** litft-g®PP LGF30 ** rau koj lub tshuab ua haujlwm uas tau xaiv cov tshuab ua kom zoo dua qub, thiab tswj hwm lub zog ua kom zoo dua qub Nrog peb mus rau engineer rau tiam tom ntej ntawm kev ua tau zoo kho lub suab tshav sunroof .
Rau cov ntaub ntawv ntau ntxiv, thov saib rau covkev qhia tshwj xeebhauv qab, lossis
Hu rau peb cov kws tshaj lij rau cov khoom siv Sunroof
Lft-g® PP LGB30 cov ntaub ntawv cov ntaub ntawv rau kev kho tshav ntuj tshav ntuj
Cov ntaub ntawv no muab cov ntaub ntawv ua haujlwm rau 30% ntev fiber ntau txhawb polypropylene (lft-g® PP LGF30) cov khoom siv, tshwj xeeb muaj feem xyuam rau cov txheej txheem huab hwm ua haujlwm, thiab cov qauv kev ruaj khov los ntawm cov khoom siv thoob ntiaj teb no tshwj xeeb datasheet ntawm koj qhov kev pab cuam rau kho cov khoom siv lft zoo .
Cov Khoom Siv Neeg Kho Tshuab
| Ntiag tug | Tus nqi | Ib yam | Kuaj Tus Qauv |
|---|---|---|---|
| Lub zog tensile | 100-130 | MPa | Iso 527-1 |
| Tensile modulus | 4000-6000 | MPa | Iso 527-1 |
| Elongation thaum so | 1.7-2.5 | % | Iso 527-1 |
| Lub zog flexural | 150-180 | MPa | Iso 178 |
| FLEXURAL Modulus | 3800-5500 | MPa | Iso 178 |
| Nonched izod cuam tshuam lub zog (+23 degree) | 36-55 | KJ / M² | ISO 180 / 1A |
| Nonched izod cuam tshuam lub zog (-30 degree) | 34-53 | KJ / M² | ISO 180 / 1A |
| Qaug zog dag zog (ntawm 106mus ncig) | 30-40 | MPa | Raws li kev sim sab hauv |
Thermal Khoom
| Ntiag tug | Tus nqi | Ib yam | Kuaj Tus Qauv |
|---|---|---|---|
| Melting kub | 210-250 | tiv kis | ISO 11357 |
|
Thaum tshav kub kub deflection kub (HDT / A, 1.8 MPA) |
150-160 | tiv kis | Iso 75-1 |
| Coefficient ntawm linear thermal expansion | 5-8 | x 10-5/K | ISO 11359 |
Lwm cov khoom
| Ntiag tug | Tus nqi | Ib yam | Kuaj Tus Qauv |
|---|---|---|---|
| Ceev | 1.1-1.12 | g / cm³ | ISO 1183 |
| Flammability (UL 94) | HB | - | UL 94 |
| Kev nqus dej noo (24 teev) | <0.05 | % | ISO 62 |
| Shrinkage tus nqi (pwm shrinkage) | 0.7-1.2 | % | ASTM D -955 |
| UV Kuj (Weathering) | Zoo (nrog ruaj khov stabilizers) | - | ISO 4892 |
Kev Siv Tshuaj Tiv Thaiv (Raug)
Lft-g® PP LGF30 cov khoom pov thawj zoo tsis kam mus rau cov tshuaj hauv qab no uas cuam tshuam rau kev tsim kho hauv tsev / vov ib puag ncig:
- Dej thiab av noo - zoo heev
- Cov Tshuaj Tiv Thaiv Me - Zoo
- Cov Roj Hmab Zoo (Siv Hauv Mechanism) - Zoo
- Diluted acids thiab alkalies - zoo
Cov ntaub ntawv ua (raug)
Cov kev pom zoo ua cov haujlwm rau LFT-G® PP LGF30 rau kev txhaj tshuaj molding ntawm Automotive Sunroof nkhaus:
- MlT kub: 200-230 degree
- Pwm kub: {30-50 degree
- Kev Txhaj Tshuaj Ceev: Nruab Nrab (optimized rau fiber ntau khaws thiab seem ruaj khov)
- Tuav Siab: Zoo rau kev txo qis warpage thiab kom ntseeg tau qhov tseeb rau kev ua haujlwm zoo
Cov Lus Qhia thiab Cov Ntaub Ntawv Ntxiv:
Cov ntaub ntawv tau los:Cov ntaub ntawv no tau muab tso ua ke raws li cov nuj nqis rau cov khoom siv lim hiam yog raws li cov khoom siv lim hiam yog raws li kev sim ua kom lub zog sab hauv?® PP LGF30 muaj kev sib xyaw ua ke muaj zog, nruj me ntsis rau kev sib txawv ntawm cov pa tshav ntuj, ua rau muaj kev sib zog ua kom sov, thiab kev ua haujlwm zoo ntawm lub hnub ci Cov ntaub ntawv ua raws cai rau cov ntaub ntawv sab hauv thiab tshav ntuj.}} Cov ntaub ntawv tshwj xeeb rau koj cov khoom siv xa khoom {}}
Download ua tiav LFT cov ntaub ntawv PDF
