Lft-g®Ntev fiber ntau txhawb polypropylene rau automotive sab hauv qhov rooj kov nkhaus
Ua rau kev ntseeg tau: ruaj pp lgf30 rau automotive sab hauv qhov rooj kov nkhaus
Lub qhov rooj sab hauv huab yog cov siv feem ntau siv hauv tsheb, raug xa rov qab rub cov rog thiab sib txawv cabin. Nws yuav tsum tau siv cov khoom uas tsis yog tsuas yog muaj zog thiab ruaj thiab tseem tswj hwm nws txoj kev ncaj ncees thiab ua haujlwm hla lub tsheb siv nyiaj. ** LFT-G®PP LGF30 ** Tawm los ua cov tshuaj uas muaj kev ua tau zoo rau kev ua kom tau cov khoom siv tes ua kom zoo sib txuas. Los ntawm kev sib xyaw 30% tas mus li ntev khob iav fibers nyob rau hauv lub siab zoo polypropylene matrix, lft-g®PP LGF30 muab txoj kev sib npaug zoo ntawm lub zog, txhav, thiab nkees ua tau zoo heev. Qhov kev tshwj xeeb no ntawm LFT PP LGF30 yog cov muaj ntau tus neeg tuaj yeem ua voj voog ntawm lub qhov rooj qhib thiab kaw kev ua tau zoo ib yam thiab tiv thaiv cov khoom tsis ua haujlwm dhau sijhawm. Nws muab cov khoom ruaj khov zoo nyob rau hauv cov ntsuas kub thiab cov av noo, tswj kev ua haujlwm zoo ntawm cov txheej txheem kov. Tsis tas li ntawd, LFT-G®PP LGF30 txhawb nqa tsheb lub cev nyhav thiab muaj cov qauv tsim qauv zoo rau cov qauv kev tsim qauv uas tuaj yeem txhim kho ob qho haujlwm thiab kev ua kom zoo nkauj sab hauv.
Qhov tseem ceeb ntawm LFT-G®PP LGF30 rau sab hauv qhov rooj kov nkhaus
- Optimized lub zog thiab nruj:Muab kev txhawb nqa kom tau txais kev txhawb nqa rau sab hauv qhov rooj kov, nrog rau cov neeg rub tawm los ntawm cov neeg siv.
- Foob Zoo Tshaj:Engineered kom withstress ntau qhov rooj qhib kev hloov mus tsis muaj cov khoom siv tsis taus, kom muaj kev cia siab ntev.
- Qhov seem ruaj khov:Khiav qauv zoo thiab haum rau hauv lub tsheb sab hauv nyob rau hauv txawv txav kub thiab av noo.
- Lub Hnav Tsho:Ua rau muaj kev txo lub tsheb hnyav tag nrho tsis muaj qhov tsis muaj kev ua tau zoo.
- Zoo saum npoo Ua Tau Peev Xwm Muaj Peev Xwm:Tso cai rau kev ua yeeb yam rau sab hauv tus qauv tsim.
- Tsim qauv tsim nyog thiab kev sib xyaw ua ke:Cov tshuaj zoo heev pab txhawb kev ua si, kev sib xyaw ua ke tsim qauv rau clacklined sib dhos.
Los ntawm kev xaiv ** litft-g®PP LGF30 ** Rau koj lub chaw muag khoom sab hauv qhov rooj sib txuas, koj tau nqis peev pab cov khoom uas tau muab cov yam ntxwv uas tseem ceeb tshaj plaws. Peb qhov tshwj xeeb LFT PP qib hloov kho cov chaw tsim tshuaj paus uas muaj zog dua, thiab tswj hwm cov neeg siv khoom sab hauv. Tshawb nrhiav cov muaj peev xwm thiab tus khub nrog peb rau engineer rau cov tiam tom ntej ntawm kev ua haujlwm siab sab hauv.
Rau cov ntaub ntawv ntau ntxiv, thov saib rau covkev qhia tshwj xeebhauv qab, lossis
Hu rau peb cov kws tshaj lij rau cov kev daws teeb meem hauv tsheb
Lft-g® PP LGF30 Cov Ntawv Cov Ntaub Ntawv Rau Kev Lag Luam Sab Hauv Qhov Rooj Khawb Caws Tes
Cov ntaub ntawv no muab cov ntaub ntawv ua haujlwm rau 30% ntev fiber ntau txhawb polypropylene (lft-g® PP LGF30) cov khoom siv, tshwj xeeb muaj feem xyuam rau kev siv tsheb sib nraus sab hauv qhov rooj kov cov ntawv thov bracket. Cov qib kawm no yog tsim los muab lub zog tsim nyog, durability, thiab seem ruaj khov rau cov siv sab hauv cov txheej txheem hauv qab cov kab ke. Cov ntaub ntawv nthuav tawm ntawm no yog raws cov txiaj ntsig tau txais los ntawm cov khoom siv thoob ntiaj teb thiab cov qauv. Thov saib cov ntaub ntawv tshwj xeeb ntawm koj qhov kev pab cuam rau cov khoom siv LFT cov nqi.
Cov Khoom Siv Neeg Kho Tshuab
| Ntiag tug | Tus nqi | Ib yam | Kuaj Tus Qauv |
|---|---|---|---|
| Lub zog tensile | 100-130 | MPa | Iso 527-1 |
| Tensile modulus | 4500-6000 | MPa | Iso 527-1 |
| Elongation thaum so | 1.7-2.5 | % | Iso 527-1 |
| Lub zog flexural | 150-180 | MPa | Iso 178 |
| FLEXURAL Modulus | 3800-5500 | MPa | Iso 178 |
| Nonched izod cuam tshuam lub zog (+23 degree) | 35-56 | KJ \/ M² | ISO 180 \/ 1A |
| Nonched izod cuam tshuam lub zog (-30 degree) | 35-55 | KJ \/ M² | ISO 180 \/ 1A |
| Qaug zog dag zog (ntawm 106mus ncig) | 30-40 | MPa | Raws li kev sim sab hauv |
Thermal Khoom
| Ntiag tug | Tus nqi | Ib yam | Kuaj Tus Qauv |
|---|---|---|---|
| Melting kub | 210-240 | tiv kis | ISO 11357 |
|
Thaum tshav kub kub deflection kub (HDT \/ A, 1.8 MPA) |
150-159 | tiv kis | Iso 75-1 |
| Coefficient ntawm linear thermal expansion | 5-8 | x 10-5/K | ISO 11359 |
Lwm cov khoom
| Ntiag tug | Tus nqi | Ib yam | Kuaj Tus Qauv |
|---|---|---|---|
| Ceev | 1.11-1.13 | g \/ cm³ | ISO 1183 |
| Flammability (UL 94) | HB | - | UL 94 |
| Kev nqus dej noo (24 teev) | <0.05 | % | ISO 62 |
| Shrinkage tus nqi (pwm shrinkage) | 0.7-1.2 | % | ASTM D -955 |
| UV Kuj (Weathering) | Zoo (nrog ruaj khov stabilizers) | - | ISO 4892 |
Kev Siv Tshuaj Tiv Thaiv (Raug)
Lft-g® PP LGF30 cov khoom pov thawj zoo tsis kam mus rau cov tshuaj hauv qab no uas muaj kev cuam tshuam rau cov khoom lag luam hauv ib puag ncig:
- Dej thiab av noo - zoo heev
- Hws - zoo
- Cov Tshuaj Tiv Thaiv Kev Tu Qub Hauv - Zoo
- Tes cream thiab potions - zoo
Cov ntaub ntawv ua (raug)
Cov kev pom zoo ua cov haujlwm rau LFT-G® PP LGF30 rau kev txhaj tshuaj molding ntawm lub qhov rooj txuas sab hauv qhov rooj kov cov nkhaus:
- MlT kub: 200-230 degree
- Pwm kub: {30-50 degree
- Kev Txhaj Tshuaj Ceev: Nruab Nrab (optimized rau fiber ntau khaws cia thiab nto tiav)
- Tuav Siab: Zoo rau kev txo qis warpage thiab kom ntseeg tau qhov tseeb thiab zoo nkauj
Cov Lus Qhia thiab Cov Ntaub Ntawv Ntxiv:
Cov ntaub ntawv tau los:Cov ntaub ntawv no tau muab tso ua ke raws li qhov tseem ceeb rau PP LGF30 los ntawm cov khoom siv thoob ntiaj teb thiab cov qauv. Kev qaug zog yog raws kev sim sab hauv. UV Yaus yog ib txwm ua tus yam ntxwv uas tsim nyog stabilizers rau cov ntawv thov sab hauv. ** LFT-G® PP LGF30 muaj qhov muaj txiaj ntsig sib npaug ntawm lub zog, kev qaug zog zoo heev, ua rau cov khoom siv noo nyob sab hauv qhov rooj kov sab hauv qhov rooj. Nws lub teeb yuag thiab cov muaj peev xwm zoo ua tiav cov peev xwm ua haujlwm sib haum xeeb thiab sab hauv cov kev cai tswjfwm. Txog cov qauv thiab cov ntaub ntawv tshwj xeeb rau koj cov programme, thov sab laj cov ntaub ntawv muab los ntawm koj cov khoom xa khoom.
Download tau tiav LFT PP LGF30 cov ntaub ntawv ntawv PDF
