60% Ntev iav Fiber PP (homo)

60% Ntev iav Fiber PP (homo)

Paub meej
Siab -Kev Ua Haujlwm 60% Ntev iav Fiber Reinforced Homo Polypropylene, yog qhov kev ua tau zoo ntawm PP GF60 luv fiber ntau sib xyaw
√ Lub ncov ntawm kev cuam tshuam tsis kam
√ Superior Low-Tsub Toughness
√ Zoo heev tawv & Toughness sib npaug
Kev faib tawm yam khoom
PP LGF Compound
Share to
Xa kev nug
Tsham tam sim no
Hauj lwm lawm
Kev tsis

LFT-G® PP LGF60-H|Qhov kawg tus qauv PP GF60

LFT-G® 60% Ntev iav fiber ntau PP (homo)

LFT-G® PP LGF60-H material - ultimate stiffness 60% long glass fiber homopolymerLFT-G®Tom ntej: PP LGF60-NG06Hyog lub apex ntawm composite kev ua tau zoo. Engineers nrhiav rau "PIB GF60" tab tom nrhiav ib yam: qhov siab tshaj plaws nruj ua tau hauv aPPsib xyaw. Txawm li cas los xij, tus qauv luv luv -fiber PP GF60 tsis muaj npe nrov thiab tsis ua rau muaj kev puas tsuaj loj. Peb LFT-G® LFRTqib yog qhov kev daws teeb meem.

Peb ua tiav qhov no los ntawm kev sib xyaw ua ke60% iav fiber ntau ntevskeleton nrog rau siab - cuam tshuamHomopolymer PPmatrix. Qhov kev sib koom ua ke no tsim ib qho "tsis muaj -kev sib haum xeeb" cov khoom uas xa cov hlau -zoo li rigidity rau cov qauv kev ncaj ncees, *ntxiv* lub zog nqus dej loj heev thiab qis -kub ductility ntawm copolymer. Nws yog cov hlau zoo kawg nkaus - hloov cov khoom siv rau qhov hnyav, dynamic ib puag ncig.

  • √ Extreme Structural Rigidity:Lub 60% LGF load muab lub flexural modulus tshaj 13,000 MPa, nyuaj tuag- nrum hlau thiab tshem tawm creep.
  • √ Kev cuam tshuam tsis sib xws:Lub hauv paus Copolymer ua kom cov khoom nyob twj ywm thiab tawg -tiv taus txawm tias nyob rau hauv -40℃tej yam kev mob uas tag nrho lwm cov yas tawv tsis ua hauj lwm.
  • √ Superior Fatigue & Vibration Damping:Coviav fiber ntau ntevnetwork tau raug pov thawj los tiv thaiv ntau lab micro- vibration cycles, ua rau nws zoo tagnrho rau cov khoom xws li lub tshuab ntxhua khaub ncaws nruas.
  •



Yam khoom yam khoom

Cov txiaj ntsig hauv qab no yog cov ntaub ntawv raug rau LFT-G®PP LGF60 -NG06H (natural homopolymer qib) thiab yog rau siv xwb.Thov hu rau peb rau Daim Ntawv Teev Npe Cov Ntaub Ntawv (TDS).

Mechanical Properties

Khoom Txoj Kev Xeem Tus nqi
Tensile Modulus TS EN ISO 527 14,000 MPa
Tensile zog TS EN ISO 527 165 MPa
Tensile Strain ntawm Break TS EN ISO 527 2.0 %
Flexural Modulus ISO 178 13,000 MPa
Notched Izod cuam tshuam (23 degree) ISO 180 / A 25 kJ/m²
Notched Izod cuam tshuam (-30 degree) ISO 180 / A 15 kJ/m²



Thermal & Physical Properties

Khoom Txoj Kev Xeem Tus nqi
Qhov ntom TS EN ISO 1183 1.40 g / cm³
HDT/A (1.8 MPa) ISO 75 165 degree
HDT / C (8.0 MPa) ISO 75 150 degree
Melting kub ISO 11357 Kev Tswj Xyuas Kev Lag Luam ~ 165 degree
Pwm Shrinkage (Flow) TS EN ISO 294-4 0.1 - 0.3 %







Cov ntaub ntawv ua haujlwm

Cov txiaj ntsig hauv qab no yog cov lus pom zoo. Peb pom zoo kom desiccant / cua tshuab ziab khaub ncaws (cov dej noo hauv qab 0.1%).

Txhawm rau txo qis fiber ntau tawg thiab ua kom pom kev ua tau zoo, qhov qis - compression, dav - lub hom phiaj ntsia hlau yog pom zoo.

Parameter Kev pom zoo
Qhuav kub 80 - 100 degree
Lub Sijhawm Qhuav 2 - 4 teev
Melt kub (Nozzle ③) 240 - 270 degree
Pwm Kub (Zone ②) 60 - 90 degree
Rov Qab Siab Tsawg (kom txo qis fiber ntau puas)

Injection molding Process info





Case Study: Industrial HVAC Blower Housing

Teeb meem

Ib chav tsev tshuab tshuab loj loj, nyob hauv ntau-ib feem ntawm cov hlau sib dhos, ua tsis tiav. Cov hlau yog hnyav, kim, thiab kis tau ntau lub suab nrov thiab kev co. Lub tsev kuj tseem yuav tsum tau ua haujlwm nyob rau hauv siab - cua sov (80℃+) Hoobkas ib puag ncig.

Kev daws

Ib qho - txhaj tshuaj tau tsim nrog LFT-G®PP LGF60-H. 60% yogiav fiber ntau ntev(LFRT) qauv muab qhov nruj nruj uas xav tau los tswj qhov kev ruaj ntseg thiab lub cev muaj zog ntawm qhov kub thiab txias. Lub hauv paus PP muab kev vibration damping zoo dua piv rau cov hlau.

Kev tshwm sim

LFT ib feem sib sau ua ke 8 daim hlau rau hauv ib qho. Nws yog60% sib dua, txo lub sij hawm sib dhos los ntawm50%, thiab txo tus nqi tsev. Cov nyhuv vibration damping kuj ua rau ib15% txo cov suab nrov(dBa).

Daim ntawv thov rau Extreme Stiffness LFT-PP (Homo)

A large structural base for a washing machine, replacing a concrete counterweight.jpg

Tshuab ntxhua khaub ncaws Base

Qhov no yog cov hlau tiag tiag - daim ntawv thov hloov. Qhov siab nruj ntawm LFTPPLGF60-H tso cai rau nws ua haujlwm raws li tag nrho cov khoom thauj-cov kabmob chassis ntawm cov khoom siv, hloov cov pob zeb lossis ntau-ib feem hlau thav duab. Nws muab cov rigidity thiab vibration damping xav tau los tswj kev kub ceev spin cycles, ib qho tseem ceeb siv rau ib tugLub tshuab ntxhua khaub ncaws nruasqhov system.

Automotive Sunroof Ncej

A perfect application for LFT-G® PP LGF60-H. The material's extreme stiffness and high thermal resistance (HDT >160 degree) tiv thaiv qhov loj, nyias thav duab los ntawm warping nyob rau hauv lub tshav kub. Qhov no ua kom muaj kev sib khi zoo meej tiv thaiv cua thiab dej rau lub neej ntawm lub tsheb, hloov hnyav dua, nyuaj aluminium thav ntawv.

car Sunroof Frames by LFT-G PP LGF Material.png

A structural industrial pump baseplate replacing cast iron made by LFT-G PP LGF NG04

Muaj Pump Baseplates

Hloov hnyav, corrosion-nrawm cam khwb cia hlau. Lub siab tawv thiab nkag siab ntawm 60% ntev iav fiber ntau (LFRT) qauv ua kom lub twj tso kua mis thiab lub cev muaj zog nyob rau hauv kev sib raug zoo, thaum lub hauv paus PP muaj tag nrho cov tshuaj tiv thaiv thiab damps vibration, txo cov suab nrov thiab ncua kev pab cuam lub neej.

Cov lus nug tseem ceeb teb

1. Dab tsi yog cov khoom siv polypropylene nruj?

A: Ntev-fiber reinforced polypropylene (LFRT) yog qhov ruaj khov dua li cov qauv luv luv- fiber ntau qib. LFT-G®PP LGF60-H (60%)iav fiber ntau ntevHomopolymer) sawv cev rau qhov siab tshaj plaws ntawm qhov tawv nqaij, nrog lub flexural modulus mus txog 13,000 MPa, ua rau nws yog tus neeg sib tw ncaj nraim kom tuag- nrum hlau zoo li txhuas.

2. Dab tsi yog qhov tsis zoo ntawm cov iav fiber ntau (xws li PP GF60)?

A: Nrog cov qauv * luv * fibers, siab filling (xws liPIB GF60) ua rau huab cua brittleness thiab tsis zoo cuam tshuam lub zog. Qhov no yog qhov teeb meem tiag tiag uas peb LFRT thev naus laus zis daws tau. Los ntawm kev siviav fiber ntau ntev, peb tsim cov pob txha sab hauv uas nres cov kab nrib pleb, khaws cov tawv tawv tseem ceeb txawm tias ntawm 60% fiber ntau cov ntsiab lus, SGF ua tsis tau.

3. Cov polypropylene puas tuaj yeem hloov pauv tuag- nrum txhuas?

A: Yog, kiag li. Rau ntau yam qauv (xws li lub hnub ci thav duab lossistshuab ntxhua khaub ncawssystems), LFT-G®PP LGF60-H yog qhov kev xaiv zoo tshaj. Nws muaj qhov tawv tawv zoo dua - rau - qhov hnyav piv (tshaj 50% sib dua li txhuas), yog corrosion-proof, thiab tso cai rau kev sib koom ua ke, uas txo qis kev tsim cov nqi thiab kev nyuaj.

Npaj txhij rau Engineer qhov Kev Sib Tw Tom ntej?

Ua kom koj cov khoom ua tau zoo nrog cov tawv tawv thiab hlau- hloov peev xwm ntawm LFT-G®60% Ntev iav fiber ntau PP (homo). Hu rau peb cov kws tshaj lij cov khoom siv niaj hnub no los tham txog koj qhov project lossis thov cov qauv khoom siv.



Cim npe nrov: 60% ntev iav fiber ntau pp (homo), Tuam Tshoj, tuam ntxhab, lwm tus muag khoom, Hoobkas, yuav, customized
