LFT-G® PA66 LGF30|Lub Siab -Tshav Kub & Fatigue Upgrade rau PA66 GF30
LFT-G® 30% Ntev iav fiber ntau PA66 (High Strength) PA66 GF 30 yog tus qauv kev lag luam rau siab - qhov kub ntawm cov qauv, nyiam tshaj PA6 rau nws cov ntsiab lus melting ntau dua. Txawm li cas los xij, nyob rau hauv ib puag ncig nrog cyclic thermal stress (cua sov thiab txias) thiab kev co, cov qauv luv fibers feem ntau debond, ua rau qaug zog tawg thiab xau.LFT-G® PA66-LGF30-NG03 yog qhov kev daws teeb meem engineering.
Qhov no Natural Qib (NG03) composite txhawb nqa siab -crystallinePolyamide 66 (Nylon 66) matrix nrog a30% Ntev iav Fiber cev pob txha. Qhov kev sib xyaw ua ke no khaws cov cua sov siab ntawm PA66 (txog 250℃lub sijhawm luv luv) thaum txhim kho kev qaug zog thiab kev nkag siab, ua kom cov khoom tuav lawv cov duab thiab foob nyob rau hauv huab cua kub caij tsheb kauj vab.
√ Superior Thermal Fatigue: Lub entangled fiber network resists tawg propagation tshwm sim los ntawm expansion/contraction cycles, extending ib feem lub neej nyob rau hauv lub cav bays.√ Ntau dua Load ntawm Kub: PA66 LGF30 tuav nruj ntawm qhov kub thiab txias qhov twg PA6 yuav mos, txhawb nqa hnyav dua ntawm 120℃+.√ Warp Resistance: Qhov qis qis anisotropic shrinkage piv rau luv luv -fiber PA66, uas ua rau flatter, ntau qhov tseeb qhov tseeb.
Thermal Fatigue Gap Kev ua tau zoo nyob rau hauv cyclic cua sov (piv txwv li, lub cav pib / nres lub voj voog) + kev vibration load.
* Raws li kev ntsuas kub ceev ceev (-40℃rau +140℃).
Yam khoom yam khoom Cov txiaj ntsig hauv qab no yog cov ntaub ntawv raug rau LFT-G® PA66-LGF30-NG03 (Natural Grade) thiab yog rau siv xwb. Cov ntaub ntawv yog rau Dry-As-Molded (DAM) xeev. Thov hu rau peb rau Daim Ntawv Teev Npe Cov Ntaub Ntawv (TDS).
Mechanical Properties
Khoom Txoj Kev Xeem Tus nqi (DAM)
Tensile Modulus TS EN ISO 527 11,500 MPa
Tensile zog TS EN ISO 527 182 MPa rau
Tensile Strain ntawm Break TS EN ISO 527 2.5 %
Flexural Modulus ISO 178 9,200 MPa
Notched Izod cuam tshuam (23 degree) ISO 180 / A 31 kJ/m²
Notched Izod cuam tshuam (-30 degree) ISO 180 / A 18 kJ/m²
Thermal & Physical Properties
Khoom Txoj Kev Xeem Tus nqi
Qhov ntom TS EN ISO 1183 1.37 g / cm³
HDT/A (1.8 MPa) ISO 75 250 degree
HDT / C (8.0 MPa) ISO 75 210 degree
Melting kub ISO 11357 Kev Tswj Xyuas Kev Lag Luam ~ 262 degree
Pwm Shrinkage (Flow) TS EN ISO 294-4 0.3 - 0.6 %
Cov ntaub ntawv ua haujlwm Cov txiaj ntsig hauv qab no yog cov lus pom zoo. Peb pom zoo kom desiccant / cua tshuab ziab khaub ncaws (cov dej noo hauv qab 0.1%).
Txhawm rau txo qis fiber ntau tawg thiab ua kom pom kev ua tau zoo, qhov qis - compression, dav - lub hom phiaj ntsia hlau yog pom zoo.
Parameter Kev pom zoo
Qhuav kub 80 - 100 degree
Lub Sijhawm Qhuav 4 - 6 teev
Melt kub (Nozzle ③) 270 - 300 degree
Pwm Kub (Zone ②) 70 - 110 degree
Rov Qab Siab Tsawg (kom txo qis fiber ntau puas)
Case Study: Automotive Radiator End Tank
Ib qho tseem ceeb ntawm lub cav txias tivthaiv. Tshem tawm cov cua kub cua txias (115℃+) thiab lub cav vibration.
Root Cause Analysis (RCA) TSEEM CEEB: Keeb kwmPA66 GF 30 tso tsheb hlau luam tsim tawm los ntawm lub hose txuas barb tom qab 50,000 km.
QHIA: Thermal Creep . Lub clamp tas mus li ua ke nrog cov cua sov ua rau luv luv - fiber ntau nylon deform ("so"), tawg lub foob.
SOLUTION & RESULT: Hloov mus rauLFT-G® PA66-LGF30 . Lub cev pob txha ntev fiber ntau tiv taus creep deformation. Cov dej ntws tawm tau raug tshem tawm, dhau 3,000-teev kev ntsuas lub zog siab.
High-Tswv Cuab/Pressure Zone Applications
Hloov cov hlau. PA66 LGF30 withstands lub siab boost siab thiab ceev kub spikes ntawm turbocharged huab cua tsis ballooning.
🚈
Railway Insulating Liners
Hluav taws xob cais ntawm txoj kab. Yuav tsum muaj sia nyob huab cua compressive loads los ntawm tsheb ciav hlau thiab UV raug. LFT PA66 muaj qhov ntev zoo dua - lub sijhawm ua haujlwm ntev dua PA6.
⚡
Circuit Breaker Bobbins
Internal coil txhawb nqa. Lub siab melting point ntawm PA66 (260 degree) ua kom cov bobbin tsis yaj thaum lub sij hawm luv luv -circuit heat spikes, tswj kev nyab xeeb.
Cov neeg tseem nug (Google PAA)
1. Qhov txawv ntawm PA6 GF30 thiab PA66 GF30 yog dab tsi?
A: Qhov sib txawv tseem ceeb yog qhov kub tsis kam.PA66 GF 30 muaj qhov melting point ntau dua (kwv yees . 260 degree) piv rau PA6 (220℃). Qhov no ua rau PA66 zoo dua rau siab - qhov kub thiab txias ib puag ncig zoo li cov khoom siv cav. Txawm li cas los xij, PA6 feem ntau muaj qhov ua tiav zoo dua thiab muaj kev cuam tshuam toughness. LFT-G® PA66-LGF30 muab qhov zoo tshaj plaws ntawm ob qho tib si: kev kub siab ua haujlwm nrog kev txhim kho toughness.
2. Qhov kub siab tshaj plaws rau PA66 GF30 yog dab tsi?
A: Qhov Kub Deflection Temperature (HDT) ntawm LFT-G®PA66 LGF 30 yog kwv yees250 degree (ntawm 1.8 MPa load). Rau kev pabcuam tas mus li, nws feem ntau tuaj yeem tiv taus 130℃-150℃nyob ntawm kev thauj khoom thiab kub stabilization additives siv, ua rau nws zoo dua rau PP lossis tus qauv PA6.
3. Puas yog PA66 GF30 muaj zog?
A: Yog, muaj zog heev. Txheem PA66 GF30 yog nruj, tab sisLFT-G® PA66-LGF30 (Long Fiber) muaj zog heev ntawm kev qaug zog thiab cuam tshuam. Cov fibers ntev tsim cov qauv kev sib txuas uas tiv thaiv kev tawg ntawm kev sib kis raws li kev thauj mus los, ua rau nws muaj peev xwm hloov pauv rau tuag- nrum txhuas hauv ntau daim ntawv thov.
Npaj los tuav lub tshav kub? Txhim kho kom zoo dua thermal stability thiab qaug zog tsis kam ntawm LFT-G® PA66 LGF 30. Hu rau peb cov kws tshaj lij cov ntaub ntawv niaj hnub no los tham txog koj qhov project lossis thov cov qauv khoom siv.
