LFT-G® PA6 LGF40 Ntev iav Fiber Reinforced Nylon Composite
Tshaj Tawm Zog: Engineered rau Impact & Endurance
PA6-LGF40 yog ntau tshaj ibsiab -lub zogkhoom-nws yog ib qho kev tsim kho toughness tov. Ntxiv nrog 40% iav fibers ntev, nws khaws cov txheej txheem rigidity thaum muab lub zog nqus zoo thiabcuam tshuam tsis kam, ua rau nws tsim tshwj xeeb los tswj cov khoom siv hluav taws xob thiab cov kev ntxhov siab tsis txaus ntseeg hauv cov ntawv thov.
Cov khoom no qhia tau hais tiaskev ruaj ntseg ntevthiabqaug zog kujnyob rau hauv txoj kev nyuaj siab, zoo tiv thaiv deformation thiab kev ua haujlwm degradation dhau sijhawm. Nws kuj muab qhov zoo tshaj plaws ntawm qhov tseeb thiab tshuaj lom neeg ua haujlwm, ua kom ntseeg tau tias kev ua tau zoo thoob plaws qhov chaw sib txawv thiab kev ua haujlwm, yog li txuas ntxiv kev pabcuam lub neej ntawm cov khoom.
Los ntawm cov khoom siv hauv kev lag luam uas ua rau muaj kev cuam tshuam rov qab rau cov khoom siv hauv tsheb uas xav tau kev nyab xeeb siab, thiab ntxiv rau cov khoom siv ruaj khov, PA6-LGF40 muab cov txheej txheem sib sib zog nqus. Nws ua rau cov khoom lag luam ua tsis tau tsuas yog muaj zog tab sis kuj hloov tau ntau dua rau cov kev xav tau ntawm kev siv lub ntiaj teb tiag tiag, ua lub hauv paus rau kev ua haujlwm ntev thiab kev ntseeg siab tsim.
Kev ua tau zoo Spectrum ntawm PA6 LGF40
Nco tseg: Qhov kev ntsuam xyuas sib piv no yog muab los ntawm cov ntaub ntawv xeem tus qauv rau cov khoom tseem ceeb
Xaiv PA6-LGF40 yog:
- Koj xav tau siab toughness thiab cuam tshuam tsis kam
- Koj qhov project yog tus nqi -sensitive
- Koj tsis xav tau hluav taws xob conductivity
- Koj tab tom hloov cov hlau lossis cov qauv yas rau lub teeb yuagsaib ntxiv
Xav txog PA6-LCF40 yog:
Koj xav tau conductivity lossis siab zog dua.saib ntxiv
Xav txog PA66-LCF40 yog:
You face high continuous operating temperatures (>150 degree).saib ntxiv
Kev Tshawb Fawb Txog Kev Ua Haujlwm: Cov ncauj lus qhia ntxaws ntxaws
| Khoom | Txoj Kev Xeem | Tus nqi | Chav tsev |
|
Tensile zog
|
ISO: 527
|
207
|
MPa |
|
Tensile Modulus
|
ISO: 527
|
13690
|
MPa |
|
Tensile Elongation
|
ISO: 527
|
1.6-2.5%
|
/ |
|
Flexural zog
|
ASTM D-790 Cov Lus Qhia Tshwj Xeeb
|
308 | MPa |
|
Flexural Modulus
|
ASTM D-790 Cov Lus Qhia Tshwj Xeeb
|
10856
|
MPa |
|
Notched Izod cuam tshuam
|
ISO: 180
|
39 |
KJ/m2
|
Download tau tiav PA6 LGF40 Daim Ntawv Teev Npe PDF
Cov ntawv thov tseem ceeb ntawm PA6-LGF40
Automotive Structure Cheebtsam
PA6-LGF40 yog siv dav hauvcav npog, pem hauv ntej -end modules, thiab lub rooj zaum. Nws zoo heev nruj thiab qaug zog tiv thaiv kom ntev -lub sij hawm kev ntseeg siab nyob rau hauv lub hood, thaum nws qhov kev vibration damping thiab lub teeb yuag zog pab ncaj qha rau kev txhim kho tsheb NVH kev ua tau zoo thiab roj efficiency.
Muaj Machinery & Cov cuab yeej fais fab
Cov khoom siv ua qhov kev xaiv zoo tshaj plaws raurobotic caj npab Cheebtsam, iav lub cev muaj zog, thiab cov khoom siv hluav taws xob. Nws cov kev cuam tshuam zoo tshaj plaws tiv thaiv kev rov ua dua thiab kev poob qis, thaum nws qhov kev ruaj ntseg thiab nkag siab zoo tswj xyuas qhov tseeb hauv qhov chaw muaj zog lossis siab -load puag ncig.
Siab -Ua tauance Sports & Mobility Equipment
Los ntawmsnowboard khisthiabtsheb kauj vab crank caj npabrau e-scooter stems thiab drone caj npab qauv, PA6-LGF40 muab cov kev sib txuas tseem ceeb ntawm qhov hnyav, siab rigidity, thiab zoo heev cuam tshuam kev nqus. Qhov no tso cai rau kom muaj zog dua, sib dua, thiab ntau dua cov qauv tsim uas ua tau raws li cov kev xav tau nruj ntawm kev ua kis las thiab daim ntawv thov kev txav mus los ntawm tus kheej.
FAQ
Q: Yuav ua li cas PA6-LGF40 txo tag nrho cov nqi piv rau hlau?
A: Nws ua kom muaj kev sib koom ua ke (hloov ntau qhov hlau nrog ib qho molded tivthaiv), tshem tawm cov txheej txheem thib ob, thiab txo qhov hnyav rau qis zog noj, muab kev txuag nyiaj ntau hauv kev tsim khoom thiab kev ua haujlwm.
Q: Nws puas tuaj yeem siv rau kev tsim qauv, kev sib xyaw ua ke?
A: Yog. Nws cov dej ntws zoo heev thiab kev ua tau zoo tso cai rau cov molding ntawm intricate geometries nrog ua - nyob rau hauv cov yam ntxwv, yooj yim los ua ke thiab txhim kho cov qauv kev ncaj ncees nyob rau hauv lub teeb yuag designs.
Q: Thaum twg kuv yuav tsum xaiv PA6-LGF40 tshaj cov qib carbon fiber ntau?
A: Xaiv PA6-LGF40 thaum koj qhov tseem ceeb yog qhov ua tau zoo ntawm kev cuam tshuam, kev ua tau zoo, thiab kev ua haujlwm sib luag. Xaiv cov qib carbon fiber ntau thaum qhov siab tshaj plaws nruj thiab lub zog tensile yog qhov tseem ceeb.
Tshaj Tawm Cov Khoom Siv: Tus khub rau Kev Tsim Kho Advanced
Ua kom koj tus qauv tsim nrog peb cov qib siab ntev - iav- fiber ntau sib xyaw. Koom tes rau qhov ua tau zoo tshaj plaws.
