Lft-g®Ntev iav Fiber cuam txhawb nqa PA6 rau kev muaj twj
Ua rau cov chaw hnyav: High-zog PA6 LGF40 rau kev muaj twj tso kua mis
Muaj cov chaw tso tsheb khiav haujlwm ua haujlwm hauv kev xav tau, raug cov tshuaj muaj zog, thiab cov neeg siv tshuaj tsis txaus, thiab lub sijhawm ntev.Lft-g®PA6 LGF40Tawm los ua cov txheej txheem txheej txheem ua ntej rau kev ua haujlwm ua kom muaj twj tso kua mis}}®PA6 LGF40 tau muab cov khoom siv tshuab hluav taws xob ntau, ua kom muaj qhov ntsuas kub ntawm LA6 thiab tej twj tso kua mis tsis tu ncua dhau sijhawm {{6} Xaiv lft-g®PA6 LGF40 ua rau lub teeb tseem ceeb piv rau lub neej tsoos tsho thiab kev siv hluav taws xob zoo nkauj thiab kev ua haujlwm zoo {}
Qhov tseem ceeb ntawm LFT-G®PA6 LGF40 rau kev muaj twj tso kua mis
- Lub zog siab heev thiab nruj:Muab cov txheej txheem ruaj khov tseem ceeb rau muaj cov kev ntsuas siab sab hauv tau pom hauv cov kua roj kev siv tshuab {}}
- Tshwj xeeb creep Kuj:Tswj txoj kev ruaj khov thiab kev ua tau zoo nyob hauv qab thauj khoom thiab kev ntsuas tshaj ncua sij hawm, ua kom muaj kev txhim khu kev qha ua haujlwm {}}
- Kev Ntsuas Cov Tshuaj Kuj:Muaj kev tiv thaiv zoo heev rau ntau cov kua muaj kua, nrog rau dej, roj, thiab cov kuab tshuaj, tseem ceeb rau ntau daim ntawv thov .
- Kev Kub Siab Tshaj:Engineered ua kom muaj kev ntseeg siab ntawm cov kub kub feem ntau tam sim no nyob rau hauv kev siv twj tso pa tawm haujlwm {}}
- Puas Txhob thiab Corrosion Kuj:Withstands cov abrasive cuam tshuam ntawm cov kua dej ntws thiab tiv taus corrosion los ntawm lub neej ntev dua li hlau xaiv .
- Lub Hnav Tsho:Ua rau qhov hnyav hnyav muab piv rau cov cuab yeej tsoos hlau tso kua hlau, nruab nrab teeb tsa thiab txij nkawm .
- Kev tsim kev ywj pheej thiab kev sib koom ua ke:Zoo nkauj molding tso cai rau cov nyom hauv geometries thiab kev sib xyaw ua ke ntawm ntau qhov, kom ua tiav cov khoom siv tsim thiab txo cov kev sib dhos ua ke thiab txo kev sib dhos ua ke nqi {}}
Los ntawm kev qhiaLft-g®PA6 LGF40Rau koj cov tsev muaj caij, koj xaiv cov khoom siv ua kom zoo dua qub, thiab cov khoom siv hluav taws xob tshwj xeeb tau piv rau cov khoom siv ua kom zoo dua qub thiab siv tau engineer rau lwm tiam ntawm kev ua haujlwm siab muaj cov twj tso kua mis solutions.
Rau cov ntaub ntawv ntau ntxiv, thov saib rau covkev qhia tshwj xeebhauv qab, lossis
Hu rau peb cov kws tshaj lij rau kev muaj cov twj tso kua roj teeb
Lft-g® PA6 LGF40 Cov Ntawv Cov Ntaub Ntawv rau Muaj Twj Tso Kua Mis
Cov ntaub ntawv no muab cov ntaub ntawv kev ua haujlwm rau 40% ntev fiber ntau txhawb polyamide 6 (lft-g® PA6 LGF40) Cov khoom siv tshwj xeeb rau kev xav tau cov khoom siv roj teeb thiab cov qauv siv hluav taws xob tau txais los ntawm cov ntaub ntawv tso tawm hauv nruab nrab, thiab cov qauv siv hluav taws xob}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}}} Thov saib cov ntaub ntawv tshwj xeeb ntawm koj qhov kev pab cuam rau kho cov khoom siv LFT qhov tseem ceeb .
Cov Khoom Siv Neeg Kho Tshuab
| Ntiag tug | Tus nqi | Ib yam | Kuaj Tus Qauv |
|---|---|---|---|
| Lub zog tensile | 170-200 | MPa | Iso 527-1 |
| Tensile modulus | 1100-12000 | MPa | Iso 527-1 |
| Elongation thaum so | 1.7-2.5 | % | Iso 527-1 |
| Lub zog flexural | 260-280 | MPa | Iso 178 |
| FLEXURAL Modulus | 9700-10000 | MPa | Iso 178 |
| Nonched izod cuam tshuam lub zog (+23 degree) | 35-55 | KJ / M² | ISO 180 / 1A |
| Nonched izod cuam tshuam lub zog (-30 degree) | 34-53 | KJ / M² | ISO 180 / 1A |
| Qaug zog dag zog (ntawm 106mus ncig) | 50-65 | MPa | Raws li kev sim sab hauv |
Thermal Khoom
| Ntiag tug | Tus nqi | Ib yam | Kuaj Tus Qauv |
|---|---|---|---|
| Melting kub | 243-270 | tiv kis | ISO 11357 |
|
Thaum tshav kub kub deflection kub (HDT / A, 1.8 MPA) |
200-210 | tiv kis | Iso 75-1 |
| Coefficient ntawm linear thermal expansion | 2-5 | x 10-5/K | ISO 11359 |
Lwm cov khoom
| Ntiag tug | Tus nqi | Ib yam | Kuaj Tus Qauv |
|---|---|---|---|
| Ceev | 1.42-1.44 | g / cm³ | ISO 1183 |
| Flammability (UL 94) | HB, v -2, lossis v -0 (nyob ntawm qib) | - | UL 94 |
| Kev nqus dej noo (24 teev) | 0.8-1.2 | % | ISO 62 |
| Shrinkage tus nqi (pwm shrinkage) | 0.3-0.7 | % | ASTM D -955 |
| Creep resistance (ntawm tshwj xeeb temp / load) | Zoo tshaj | - | ISO 899 |
Kev Siv Tshuaj Tiv Thaiv (Raug)
Lft-g® PA6 LGF40 Cov khoom pov thawj zoo rau kev ua kom zoo rau cov tshuaj hauv qab no cuam tshuam nrog kev siv roj ua pa:
- Dej (kub & txias txias) - zoo heev
- Roj thiab Greases - Zoo Tshaj
- Fuels - Zoo
- Cov acids thiab cov hauv paus siab - zoo (siab thiab ntsuas kub)
- Ntau cov kuab tshuaj thiab tshuaj lom neeg - zoo (tshwj xeeb kev ntsuas pom zoo)
Cov ntaub ntawv ua (raug)
Cov kev pom zoo ua cov haujlwm rau LFT-G® PA6 LGF40 RAU Txhaj Tshuaj Molding Ntawm Muaj Twj Tso Cai Caij Twj:
- MlT kub: 250-280 degree
- Pwm kub: {80-120 degree
- Kev Txhaj Tshuaj Ceev: Nruab Nrab (optimized rau fiber ntau khaws cia thiab sau cov geometries ncaj ncees)
- Tuav Siab: Zoo rau kev ua kom tsis txhob muaj kev tawm tsam thiab ua kom pom tseeb qhov tseeb thiab cov khoom muaj zog
- Kom qhuav: ** Qhov tseem ceeb ** Ua ntej ua tiav (feem ntau {{{}}℃rau {} hygroscopic xwm .
Cov Lus Qhia thiab Cov Ntaub Ntawv Ntxiv:
Cov ntaub ntawv tau los:Cov ntaub ntawv no tau muab tso ua ke raws li cov nuj nqis rau PA6 LGF40 los ntawm kev ua kom thoob ntiaj teb cov khoom lag luam yog cov kev ua tau zoo {}} ** lft-g® PA6 LGF40 yog qhia tshwj xeeb rau cov khoom siv hauv cov roj ntsha ua kom zoo nkauj Kev ua kom zoo tshaj plaws thiab ua tiav cov khoom siv mechanical {}}} tej ntaub ntawv ua haujlwm ntsig txog koj cov ntaub ntawv ntsuas kub thiab siv tau los ntawm koj cov khoom siv hluav taws xob.
Download tau tiav LFT PA6 Cov Ntawv Sau PDF
