Name: Tuam Tshoj LFT-G® PP CF40|Ntev Carbon Fiber Reinforced Polypropylene (LCF40) Hoobkas, Chaw tsim khoom thiab cov chaw muag khoom - LFT-G
Brand: LFT-G
SKU: 289210458

LFT-G® CPP-LCF40 (BC04B)|Kev coj tus yam ntxwv & Ultra-Tshuaj PP CF40

LFT-G® 40% Ntev Carbon Fiber PP (Copo Qib)

Nrhiav siab -modulusPIB CF40khoom?LFT-G^®CPP{0}}LCF40(Model: CPP-BC04B) yog cov khoom zoo tshaj plaws uas thawb cov ciam teb ntawm Polypropylene. Los ntawm kev txhawb zog tawvCopolymer PPmatrix nrog40% Ntev Carbon Fibers, peb tsim cov khoom siv uas tsis yog ultra- hnyav xwb tab sis kuj muaj hluav taws xob.

Engineered rau kev ua tau zoo heev, peb cov pellets yog tsim los hloov cov hlau (aluminium, magnesium) thiab kim engineering yas xws li PA66-GF. The Copo-PP base ensures high impact toughness, while the dense carbon fiber network provides exceptional creep resistance and naturalEMI kev tiv thaiv, ua rau nws zoo tagnrho rau automotive electronics thiab aerospace Cheebtsam.

√ Superior Skeletal Network:LFT thev naus laus zis ua kom cov fibers nyob ntev hauv cov matrix, tsim cov pob txha uas tiv thaiv kev tawg tawm thiab txhawb kev cuam tshuam lub zog los ntawm 2-3x dhau luv fiber ntau CF40.
√ Zoo heev EMI Shielding:Lub siab 40% cov ntsiab lus carbon tsim ib txoj hauv kev, muab kev tiv thaiv electromagnetic cuam tshuam rau cov khoom siv hluav taws xob.
√ Dimensional Stability:Exhibits tsis tshua muaj shrinkage thiab warpage, kom ntseeg tau precision tolerances nyob rau hauv loj structural qhov chaw xws li ntsuas vaj huam sib luag nqa.

Quote Tus Qauv Nug

Functional Advantage: EMI Shielding

40% Carbon Fiber tsis yog muaj zog xwb; nws yog conductive. Nws tiv thaiv hluav taws xob los ntawm kev cuam tshuam yam tsis muaj hlau plating.

Txheem Yas / GF-PP

Wave hla dhau

Tsis muaj thaiv. Electronics yooj yim.

LFT-G® CPP-LCF40

Wave Blocked / Absorbed

Siv tau EMI/RFI Shielding.

Yam khoom yam khoom (BC04B)

Cov txiaj ntsig hauv qab no yog cov ntaub ntawv raug rau LFT-G^®CPP-LCF40 (National Carbon Qib) thiab yog rau siv xwb. Cov ntaub ntawv yog rau qhuav-As-Moulded (DAM) xeev.Thov hu rau peb rau Daim Ntawv Teev Npe Cov Ntaub Ntawv (TDS).

Mechanical Properties

Khoom	Txoj Kev Xeem	Tus nqi (DAM)
Tensile Modulus	TS EN ISO 527	17,000 MPa
Tensile zog	TS EN ISO 527	120 MPa
Tensile Strain ntawm Break	TS EN ISO 527	1.2 %
Flexural Modulus	ISO 178	13,000 MPa
Notched Izod cuam tshuam (23 degree)	ISO 180 / A	PEB 52 kJ/m²
Nto Resistivity	ASTM D 257 Cov	10³ - 10⁴Ω / sq (Kev coj tus kheej)

Thermal & Physical Properties

Khoom	Txoj Kev Xeem	Tus nqi
Qhov ntom	TS EN ISO 1183	1.04 g / cm³
HDT/A (1.8 MPa)	ISO 75	162 degree
HDT / C (8.0 MPa)	ISO 75	115 degree
Melting kub	ISO 11357 Kev Tswj Xyuas Kev Lag Luam	~ 165 degree
Pwm Shrinkage (Flow)	TS EN ISO 294-4	0.1 - 0.2 %

Download Ua tiav LFT^®CPP -LCF40 TDS (PDF)

Cov ntaub ntawv ua haujlwm

Cov txiaj ntsig hauv qab no yog cov lus pom zoo. Peb pom zoo kom desiccant / cua tshuab ziab khaub ncaws (cov dej noo hauv qab 0.1%).

Txhawm rau txo cov pa roj carbon fiber ntau, siv qhov tsawg- compression ntsia hlau thiab tsis txhob siab rov qab.

Parameter	Kev pom zoo
Qhuav kub	80 - 100 degree
Lub Sijhawm Qhuav	2 - 4 teev
Melt kub (Nozzle ③)	220 - 260 degree
Pwm Kub (Zone ②)	40 - 70 degree
Rov Qab Siab	Tsawg heev ( khaws cia fibers)

Injection molding Process info

Case Study: Industrial Drone Arm

Lightweight carbon fiber drone arm

Ib qho hnyav- nqa ua liaj ua teb drone caj npab. Yuav tsum xoom flex nyob rau hauv load thiab EMI shielding rau GPS modules.

Davhlau Performance Log

Cov khoom qub (Aluminium):
Hnyav. Txo roj teeb lub neej. Kev cuam tshuam nrog cov kav hlau txais xov sab hauv.

GF-PP (iav Fiber):
Yooj yim heev. Caj npab flexed thaum lub sij hawm ya, ua rau instability. Tsis muaj thaiv.

Tus yeej: LFT-G® CPP-LCF40
1. Qhov hnyav:40% sib dua li Aluminium.
2. Kev nruj: >17 GPa modulus tiv thaiv flexing.
3. EMI:Muab kev tiv thaiv tsim nyog rau cov khoom siv hluav taws xob.

Dual{0}}Function Zones (Structural + Conductive)

⚡

Anti-Kiv cua zoo li qub

Rau qhov chaw tawg (ATEX). Cov pa roj carbon fiber ntau tiv thaiv kev tsim kho zoo li qub- rau ntawm cov kiv cua thaum muab cov tawv tawv siab.

🚗

Center Console Carriers

Automotive interiors. Hloov magnesium. Tsis tshua muaj zog, hnav, thiab pab tiv thaiv kev thaiv hauv cov hlau los ntawm kev cuam tshuam.

🧵

Textile Yarn Guides

High -kev ceev machinery qhov chaw. Cov pa roj carbon fiber ntau txo cov kev sib txhuam, tso tawm hluav taws xob zoo li qub los ntawm cov xov txav, thiab tiv taus hnav.

Cov neeg tseem nug (Google PAA)

1. Puas yog PP CF40 conductive?

A: Yog. Ntawm 40% kev thauj khoom, carbon fibers tsim ib qho kev sib txuas ua ke hauv PP matrix.LFT-G® CPP-LCF40feem ntau muaj ib tug nto resistivity ntawm10³- 10⁴ Ω/sq, ua rau nws zoo tagnrho rau electrostatic paug (ESD) tiv thaiv thiab electromagnetic cuam tshuam (EMI) shielding daim ntaub ntawv.

2. Dab tsi yog qhov modulus ntawm PP CF40?

A: Lub tensile modulus ntawmLFT-G® CPP-LCF40yog tshwj xeeb siab, tshaj17,000 MPa (17 GPa). Qhov no yog ze li peb npaug ntawm qhov nruj ntawm cov iav txheem- puv PP (GF30 ~ 7 GPa), tso cai rau nws los hloov cov qauv hlau xws li magnesium thiab txhuas hauv qhov hnyav- qhov tseem ceeb.

3. Qhov txawv ntawm Homo-PP thiab Copo-PP yog dab tsi?

A: Homo-PP (Homopolymer) yog tawv dua tab sis nkig ntawm qhov kub thiab txias.Copo-PP (Copolymer), uas peb siv hauv LFT-G® BC04B, muaj cov ethylene blocks uas ua rau muaj kev cuam tshuam hnyav, tshwj xeeb tshaj yog nyob rau hauv qhov chaw txias. Qhov no ua rau Copo-PP yog qhov kev xaiv zoo tshaj plaws rau cov tsheb sab nrauv thiab cov drones uas yuav muaj kev cuam tshuam.

Npaj los tiv thaiv thiab ntxiv dag zog?

Tau txais qhov kawg ua ke ntawm conductivity, nruj, thiab qhov hnyav nrog LFT-G^®CPP{0}}LCF40. Hu rau peb cov kws tshaj lij cov khoom siv niaj hnub no los tham txog koj qhov project lossis thov ua qauv.

Thov ib tug qauv Hu rau tus kws tshaj lij
